Current Location：Home >> Products >> FBT Couplers >> Dual Window Coupler (DWC)

Name
Dual Window Coupler (DWC)

Description
 Dual window coupler (DWC) is built by asymmetric coupling technique. The operating bandwidth of this normal coupler is expanding to ±40nm, and the ultra broadband coupler is expanding to ±80nm. The DWC coupler has the same coupling ratio on both 1310nm and 1550nm communication windows, and with low excess loss and low PDL. DWC couplers are widely used for communication systems, CATV, and FTTH.

PDF Download
Details
