Name
High Power Circulator
Description
As a compact high performance light wave component, the PHX’s high power circulator routes incoming signals from Port 1 to Port 2, and incoming signals Port 2 to Port 3. The component provides low IL and PDL(SM), high stability and reliability. It is widely used in combination with the fiber brag gratings, reflective components optical amplifier and other fiber optical instruments. These circulators are Telcordia GR1209/1221 compliant. Customized product is available.
 PDF Download
|
